2mm 5mm 6mm 8mm 11.4g/M High Tenacity PP Yarn Polypropylene Cable Filling Rope

Jiangxi Longtai New Material Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap 2mm 5mm 6mm 8mm 11.4g/M High Tenacity PP Yarn Polypropylene Cable Filling Rope from wholesalers

    Buy cheap 2mm 5mm 6mm 8mm 11.4g/M High Tenacity PP Yarn Polypropylene Cable Filling Rope from wholesalers
    • Buy cheap 2mm 5mm 6mm 8mm 11.4g/M High Tenacity PP Yarn Polypropylene Cable Filling Rope from wholesalers
    • Buy cheap 2mm 5mm 6mm 8mm 11.4g/M High Tenacity PP Yarn Polypropylene Cable Filling Rope from wholesalers
    • Buy cheap 2mm 5mm 6mm 8mm 11.4g/M High Tenacity PP Yarn Polypropylene Cable Filling Rope from wholesalers
    • Buy cheap 2mm 5mm 6mm 8mm 11.4g/M High Tenacity PP Yarn Polypropylene Cable Filling Rope from wholesalers

    2mm 5mm 6mm 8mm 11.4g/M High Tenacity PP Yarn Polypropylene Cable Filling Rope

    Ask Lasest Price
    Brand Name : Longtai
    Model Number : PP Filler Yarn
    Certification : SGS
    Price : negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 500T/month
    Delivery Time : 25-30days
    • Product Details
    • Company Profile

    2mm 5mm 6mm 8mm 11.4g/M High Tenacity PP Yarn Polypropylene Cable Filling Rope


    pp cable filler yarn

    Features and applications:


    Using drawing level Polypropylene as raw material, extrusion forming and meshes tearing by specialized machinery,it mainly as non-hygroscopic filler for wires and cables.

    There are natural white and extremely white color,and divided into single strand and multi strands,and the former is used in low level power cable and control cable,while the latter used in cross-linked cable.

    Physical properties:

    light weight, non-hygroscopic, soft and elastic.Chemical properties:anti mildew,chemical corrosion resistant, temperature resistant and non-toxic.
    Electrical properties:High-frequency insulation is good, high breakdown voltage.
    Appearance:Expand into the mesh, soft, non-severe glitch.


    Core:Paper tube core 36mm,55mm, 76mm,and special specification can be customized.



    1. 100% PP filler yarn

    Linear Density

    12000D

    18000D

    28000D

    33000D

    48000D

    60000D

    70000D

    90000D


    (weight)g/m

    1.33+0.13
    -0.13


    2+0.2
    -0.2

    3.11+0.31
    -0.31

    3.67+0.37
    - 0.37


    5.33+0.53
    -0.53

    6.67+0.67
    -0.67

    7.77+0.77
    -0.77

    10+1.0
    -1.0


    Diameter
    (mm)

    1.5

    2

    2.5

    2.7

    3.2

    3.8

    4.5

    5


    Breaking
    Strength
    (kg)
    equal or more

    24


    36

    56

    66


    96

    120

    140


    180

    (%)
    Breaking Elongation
    equal or more

    10


    10

    10

    10


    10

    10

    10


    10



    2. Standard cable pp filler yarn with mixed Caco3 :
    0.5----30MM, 4----10 TPM
    Standard pp cable filler yarn, price is not high, good effect of cable filling,
    no knot packing, can be used in kinds of cable and wire


    Advantage: Cheap price, suitable for large cable.


    Linear Density

    D

    +/-10%

    0.5 --30MM
    Denier:9000D---300KD


    Breaking Strength

    g/D

    0.6--1.4


    Breaking Elongation

    %

    20


    Hot Shrinkage rate

    %

    6

    100°C*1min.


    Tube size

    mm

    1 ID: 90, H:255
    2. ID: 38, H:220
    3. ID: 50, H:270
    4. ID: 75, H:440
    5. ID: 55, H: 300-400


    Packing

    5----50KG/ROLL


    PP+Caco3 Wire Cable PP Filler Specificatioms

    Item

    Unit

    standard

    Remark


    pp filler Fineness

    D

    specification±8%

    9000D-300000D


    pp filler Breaking

    g/d

    >0.6g/d--1.4


    tenacity


    Tensibility

    %

    <20


    shrinkage

    %

    <10

    120*30min


    in hot air


    Appreance

    Natural Color or Milky White
