    200D 500D High Tenacity Zxion Yarn For Optical Fiber Cable Filler

    Ask Lasest Price
    Brand Name : Longtai
    Model Number : Zxion yarn
    Certification : SGS/ISO/RoHS
    Price : Negociable
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 40 Tons per month
    Delivery Time : 20~25 days after receiving deposit
    • Product Details
    • Company Profile

    200D 500D High Tenacity Zxion Yarn For Optical Fiber Cable Filler


    200D 500D High Tenacity Zxion Yarn For Optical Fiber Cable Filler


    Description:


    Zxion yarn, with high tenacity up to 30cN/dtex, high elasticity 1000cN/dtex, is widely used for electrical and electronic fields, headset, endoscope, optical fiber, printed wiring board and so on.


    1. High strength: strength up to 30cN/dtex (=4.2G*Pa) or more (high strength level)

    2. High elasticity: elasticity rate reaches 1000cN/dtex (=140G*Pa) (high elasticity level)

    3. Low dielectric rate: excellent electrical characteristics, very suitable for ultrasonic accessories

    4. Low volume expansion: The size change due to temperature is very small.

    5. Fine fineness: The fineness is below 220dtex, which can correspond to the production of single filament fineness of 2.3dtex.

    6. Various levels: high strength level, high weather resistance level, etc.

    7. Others: vibration attenuation, low water absorption, heat resistance, acid resistance, cut resistance, low creep, etc.


    Specifications:

    dtex
    Brand (Density)
    Bending Resistance of 220dtex
    the number of times
    18dtex28dtex56dtex110dtex137dtex220dtex
    555,556m/kg357,143m/kg178,571m/kg90,909m/kg72,993m/kg45,455m/kg
    StrengthDiaStrengthDiaStrengthDiaStrengthDiaStrengthDiaStrengthDia
    kgμmkgμmkgμmkgμmkgμmkgμm
    ZXION VS
    (1.41g/㎤)
    121,6800.4455.30.6970.71.3797.62.69136.93.35153.85.38198.3
    ZXION TS
    (1.41g/㎤)
    84,6600.5355.30.8370.71.6697.63.25136.94.05153.86.51198.3
    Kevlar (1.44g/㎤)40,780----1.1697.32.28134.92.84151.64.55190.7
    Technora (1.38g/㎤)8,000------2.75137.8--5.50194.9
    Vectran (1.41g/㎤)38,6200.4255.30.6570.71.3197.62.57136.9--5.14198.3


    How To order :

    1. Let me know the models, specification, quantities, colors you want to order
    2. We will email you the Proforma Invoice based on your order information
    3. Kindly check the PI, everything is ok, we will start production as soon as receiving payment deposit or LC, then
    deliver the goods on request, original documents will be send against full payment


    Shipping instructions :


    We will ensure that the goods are not damaged during delivery. Before shipment, we will arrange for the customer to conduct a video inspection to ensure that there is no problem and the goods will leave to ensure that everything is safe during transportation. We will also track the process in real time.


    After Service:


    1. Best quality and best service for any order. No problem big or small order

    2. One year warranty.

    3. Please contact after our Service Department, inform us what problem you encounter.

    4. We provide solving methods for you.
